BELDEN 8132, 28 AWG 1-PAIR SHIELDED MINIATURE INSTRUMENTATION CABLE
BELDEN 8132 is a high-precision, miniature instrumentation cable designed for space-constrained applications where standard-sized cables are impractical. Featuring a small-gauge 28 AWG conductor pair and an effective foil shield, it is the ideal solution for compact electronic equipment, high-density control panels, and intricate sensor arrays where flexibility and minimal footprint are essential.
Product Description
Despite its miniaturized profile, this cable is engineered to maintain high signal reliability in sensitive electronic environments:
Miniature Construction: It utilizes 28 AWG stranded (7x36) tinned copper conductors. This ultra-fine gauge significantly reduces the overall cable diameter, allowing for easy routing in tight, high-density enclosures where larger cabling would cause congestion or obstruct airflow.
Effective EMI/RFI Shielding: The cable is protected by a Beldfoil® (aluminum/polyester) shield that provides 100% coverage, ensuring that sensitive data signals are shielded from electromagnetic and radio frequency interference. A 28 AWG stranded tinned copper drain wire is included to simplify grounding and ensure a low-impedance path for noise drainage.
Performance-Driven Insulation: The conductors are insulated with polypropylene, which provides excellent dielectric strength and low capacitance—critical factors for maintaining signal integrity and minimizing attenuation in long-run, low-voltage electronic circuits.
Flexible and Durable: The entire assembly is encased in a chrome PVC jacket. This jacket offers a balance of flexibility, making it easy to maneuver around tight corners and through miniature cable management systems, while still providing robust protection against mechanical wear and environmental exposure.
Miniature Construction: It utilizes 28 AWG stranded (7x36) tinned copper conductors. This ultra-fine gauge significantly reduces the overall cable diameter, allowing for easy routing in tight, high-density enclosures where larger cabling would cause congestion or obstruct airflow.
Effective EMI/RFI Shielding: The cable is protected by a Beldfoil® (aluminum/polyester) shield that provides 100% coverage, ensuring that sensitive data signals are shielded from electromagnetic and radio frequency interference. A 28 AWG stranded tinned copper drain wire is included to simplify grounding and ensure a low-impedance path for noise drainage.
Performance-Driven Insulation: The conductors are insulated with polypropylene, which provides excellent dielectric strength and low capacitance—critical factors for maintaining signal integrity and minimizing attenuation in long-run, low-voltage electronic circuits.
Flexible and Durable: The entire assembly is encased in a chrome PVC jacket. This jacket offers a balance of flexibility, making it easy to maneuver around tight corners and through miniature cable management systems, while still providing robust protection against mechanical wear and environmental exposure.
